01 / DIMENSIONS & MODEL DATA
| Model / configuration | T-RV200-H8 / T-RV200-H8-CORE-STD-P200 |
|---|---|
| Chemistry / cell format | LiFePO4 / prismatic |
| Nominal voltage / capacity | 12.8V / 200Ah — approved model rating |
| Nominal energy | 2.56kWh — calculated, not measured usable energy |
| BMS reference | P200 CORE |
| Self-heating | No — CORE-STD configuration |
| Cell sourcing direction | Approved model cell configuration; refer to the final BOM and datasheet |
| Battery weight | Request the weight for the selected model configuration. |
| Intended duty / market | Motorhome and caravan house power / Europe (EU) |
Confirm the complete drawing rather than relying on the H8 designation or Ah rating. Use the RV Lithium Battery Compatibility Guide to prepare the fit review.
02 / ELECTRICAL ENVELOPE
Approved P200 CORE ratings: 200A continuous discharge / 400A peak discharge.
Use the current model-specific pack specification for peak duration, protection settings and thermal limits.
Use this platform for RV house-power evaluation. Match simultaneous loads and inverter surge to validated pack ratings, cables, fuses and disconnects. Engine-starting capability is not specified.
This CORE-STD build has no self-heating. Confirm low-temperature charge protection, charging voltage and maximum charge current before integrating a converter, solar controller or alternator/DC-DC charger.
12.8V × 200Ah = 2,560Wh nominal energy. Actual runtime depends on load, usable SOC, temperature and conversion losses.
03 / RV INTEGRATION CHECKLIST
Resolve these model-specific requirements before committing to installation, evaluation samples or production.
| Workstream | Model-specific reference | Review requirement |
|---|---|---|
| Housing & packaging | Model-specific fit review | Approve enclosure drawing, retention features, terminal clearance and packaging. Use the approved housing drawing; any custom tooling needs separate review. |
| Electrical & thermal limits | Continuous and peak operating limits | Use the approved pack limits for continuous and peak discharge, peak duration and operating temperatures. |
| Charging & system integration | Refer to final approved charging specification | Confirm charger settings, maximum charge current, protection coordination and application loads. |
| Series / parallel | Only approved series/parallel arrangements | Use only series or parallel arrangements approved for the selected BMS and system. |
| Compliance documents | Planning references only | CE / RoHS / UN38.3; IEC optional according to scope. Issued documents and attained status are not confirmed. |
| Commercial release | Project-specific review | Confirm approved model revision, OEM scope, MOQ, pricing and delivery timing. |
04 / SMART CONFIGURATION & OEM
Specify Bluetooth monitoring, CAN / RS485 integration, runtime prediction and battery-health functions against your RV system. Confirm availability for the selected BMS hardware, firmware and connected equipment; these are not assumed standard in the CORE build.
For European motorhome manufacturers, caravan integrators and battery brands, agree the terminal format, BMS parameters, brand labels, packaging and required documents as one configuration.
Review Smart BMS & AI RV Battery Technology for system options and RV Battery OEM & Private Label Solutions for development support.
No. Check the complete 353 × 175 × 190 mm approved model envelope, hold-down geometry, polarity, terminal covers and cable clearance against the approved drawing. Physical H8 / LN5 interchangeability is not universal; verify the specific installation drawing.
Use 12.8V × 200Ah = 2,560Wh for preliminary energy planning. Allow for usable SOC, temperature and conversion losses; this is not measured usable energy or a runtime guarantee.
The CORE-STD configuration has no self-heating. Bluetooth, CAN, RS485 and advanced monitoring require model-specific confirmation. The approved P200 configuration is rated 200A continuous and 400A peak discharge; confirm peak duration in the final datasheet.
Share your compartment drawing, loads, charging architecture, climate, terminal requirements, quantity and sales market. TUORDE can then review installation fit, configuration, sample availability, pricing and timing.
Send your installation drawing, load profile and purchasing requirements to discuss the T-RV200-H8-CORE-STD-P200 configuration, OEM options and ordering and integration requirements.
Request Technical Specifications
Browse existing RV battery listings →
For a different energy and packaging requirement, review the 12V 280Ah MINI Smart RV Battery. Compare its 3.584kWh nominal energy and 430 × 220 × 250 mm enclosure dimensions against this H8 platform; fit, current ratings and charging compatibility must be reviewed separately.
